Data Interfaces
The indicator is equipped with the following data interfaces:
– COM1: Standard data interface (RS-232)
– COM2: Standard data interface (RS-232)
– UniCOM: Universal data interface (optional)
Interfaces can be congured in the Setup menu for dierent input and output
functions (e.g. printer, 3rd weighing platform, PC, checkweighing).
The optional UniCOM interface can be used as an RS-232, RS-485/RS-422 or
analog output (voltage/current interface, galvanically separated digital I/Os,
probus, DeviceNet, Ethernet), see also “Accessories.“
A barcode scanner or a keyboard can be connected via the PS/2 -socket or the
corresponding screw terminals (IP69K).
Features – IP44 indicator:
Connect via a 25-pin D-Sub female connector
– IP69K indicator:
Route the connecting cable from the peripheral device to the indicator via
a cable gland. The free cable ends are connected via the screw terminals.
3
Warning when using third-party RS-232 connecting cables:
The pin assignments may not be compatible with Minebea Intec equipment.
Check the pin assignment against the cabling diagrams and disconnect any lines
that are not assigned. Failure to do so may cause malfunction, damage or even
completely ruin your indicator and/or peripheral device(s).
96 Operating Instructions Combics Complete Scales
