Specications
Serial interface: Interface operating mode: Full duplex
Level: COM1: RS-232,
COM2: RS-232,
UniCOM (optional): RS-232 or
RS-422/485 half duplex
Transmission rate: 150, 300, 600, 1200, 2400, 4800, 9600, 19200 baud
(depending on the operating mode)
Number of data bits: 7, 8 bits
Parity: Space, odd, even, none (depending on the
operating mode)
Number of stop bits: 1 or 2
Handshake mode: Software (XON/XOFF), hardware (1 character after
CTS)
Protocols: SBI, XBPI-232
2)
, XBPI-485
1)2)
, SMA,
Probus (UniCOM only) various printers:
– YDP14IS label – Universal
– YDP14IS – YDP05 – YDP21
– YDP20 – YDP04IS label
Network address
3)
: 0, 1, 2, ..., 31
SBI: Manual data output: Without stability, after stability, congurable printout
SBI: Auto. data output: Without stability, at stability
SBI: Output format: 16 or 22 characters
Printout of application data: Output of a congurable printout
Analog UniCOM interface (optional) Level: 4…20 mA, 0…20 mA, 0…10 V
Power supply: Internal
Factory setting: 4...20 mA, internal power supply
Connection: CAISL3 devices (IP44):
25-pin D-Sub socket
CAIS3 devices (IP69K):
Connection via screw terminals in the housing,
cable routed into the housing via a cable gland.
1)
Optional UniCOM universal data interface
2)
xBPI operating mode: 9600 baud, 8 data bits, parity: odd, 1 stop bit
3)
Network address is valid only in xBPI-RS-485 operating mode
Operating Instructions Combics Complete Scales 97
Data Interfaces
