99
BCD output(Option)
Output BCD 7 digit parallel output, with polarity, P.C.(Print command), Error,
OVER, Stable, Gross value
※Above is open collector output V
CE
= DC30 V, I
C
= DC20 mA MAX
Input HOLD, BCD-ENABLE
※Above is level input, and effective during the input of short more than 100
ms.
RS-232C (Option) RS-232C interface output
RS-422/485 (Option)
RS-422/485 interface output
※The changeover of RS-422 and RS-485 is made by the function.
Current output (Option)
DC4 mA to 20 mA Load resistance 510 ohm or less
Non linearity 0.05 %F.S.
Voltage output (Option)
DC0 V to 10 V Load resistance 5 k-ohm or more
Non linearity 0.05 %F.S.
15-4. General specifications
Operating temperature range
Temperature －10℃ to 40℃
Humidity 85 %RH or less (Non condensing.)
Power supply
Power supply voltage AC100 V (Permissible variable range AC85 V to AC110 V)
Power supply frequency 50/60 Hz
Power consumption
Approx. 4 VA(without options at AC100 V),
10 VA at maximum (with options at AC100 V)
Power supply AC120 V (Option)
Power supply voltage AC120 V (Permissible variable range AC102 V to AC132 V)
Power supply frequency 50/60 Hz
Power consumption
Approx. 4 VA(without options at AC120 V),
10 VA at maximum (with options at AC120 V)
Power supply AC200 V (Option)
Power supply voltage AC200 V (Permissible variable range AC170 V to AC220 V)
Power supply frequency 50/60 Hz
Power consumption
Approx. 4 VA(without options at AC200 V),
10 VA at maximum (with options at AC200 V)
Power supply AC240 V (Option)
Power supply voltage AC240 V (Permissible variable range AC204 V to AC264 V)
Power supply frequency 50/60 Hz
Power consumption
Approx. 4 VA(without options at AC240 V),
10 VA at maximum (with options at AC240 V)
Outline dimension 192 mm(W) x 96 mm(H) x 165 mm(D) (excludes protruding parts)
Weight Approx. 1.6 kg (without options)
※ When this is used in Japan domestic, the voltage that exceeds AC125 V by the limitation of “Electrical
Appliance and Material Safety Law”.
