85
13-5. Power supply voltage
The power supply voltage of this unit has AC120 V, AC200 V, and AC240 V besides of standard AC100 V.
Please use them within the following specified ranges according to the connecting method in the paragraph 2-5.
13-5-1. Power supply of AC120 V (P/N. CSD904-P62)
Power supply voltage AC120 V (Allowable variable range AC102 V to AC132 V)
Power supply frequency 50/60 Hz
Power consumption
Approx. 4 VA (without options at AC120 V)
Approx. 10 VA (with options at AC120 V)
Suitable fuse Midget fuse 0.5A
13-5-2. Power supply of AC200 V (P/N. CSD904-P63)
Power supply voltage AC200 V (Allowable variable range AC170 V to AC220 V)
Power supply frequency 50/60 Hz
Power consumption
Approx. 4 VA (without options at AC200 V)
Approx. 10 VA (with options at AC200 V)
Suitable fuse Midget fuse 0.315A
＊The power cable for AC250 V is not attached.
13-5-3. Power supply of AC240 V (P/N. CSD904-P65)
Power supply voltage AC240 V (Allowable variable range AC204 V to AC264 V
Power supply frequency 50/60 Hz
Power consumption
Approx. 4 VA (without options at AC240 V)
Approx. 10 VA (with options at AC240 V)
Suitable fuse Midget fuse 0.315A
＊The power cable for AC250 V is not attached.
Warning
● Attached AC power cable is to be used for AC125 V. When you will use the power supply of AC200 V or AC240 V, please prepare and use
the cable for AC250 V power supply separately.
● When this is used in Japan domestic, the voltage that exceeds AC125 V cannot be supplied by the limitation of “Electrical Appliance and
Meterial Safety Law”.
