12-3. Explanation of format data
(1) Automatic printing bit (FUN1：bit 0)
This bit can be used as a trigger with the serial interface receiving side equipment.
(2) Display bit (ST1：bit 7、bit 6)
bit 7：When the display of this unit is gross value, “1” is set.
bit 6：When the display of this unit is net value, “1” is set.
12-4. Explanation of output type
(1) Stream mode
It keeps outputting the data of gross value and the net value etc. at constant intervals.
(2) Automatic printing mode
When the gross value and net value make the stability detection, and meet the requirement “Data
exceeding +5D” or “Data except the range from –5D to +5D”, the automatic print bit of output format
FUN1 is set in “1” and transmits.
(3) Manual printing mode
When there are a stability detection, and the input by the key(or the external input), The
automatic print bit of output format FUN1 is set in “1” and transmits.
● The automatic printing bit is usually “0”.
● The automatic printing bit is usually “0”.
