28
5-2. Function of C function data
Item
Function No.
Setting
value
Contents
0 No decimal point
1 1234.5
2 123.45
Display position of
decimal point.
CF-01
3 12.345
0 Bigger than |The maximum capacity9D|
Condition of over display CF-03
1
Exceeding to the maximum capacity
±110 %
0 No unit
1 g
2 kg
3 t
Unit CF-05
4 lb
0 Operation when it is steady
Operating condition of
zero set
CF-10
1 Operation by unconditional
0 ±2 % of the maximum capacity
Effective range of zero
set
CF-11
1 ±10 % of the maximum capacity
0 Gross value and net value
Target of zero tracking CF-12
1 Gross value
0099
Data width of zero
tracking
CF-13
01
Unit : 0.5 D
00 : Zero tracking OFF
09
Time width of zero
tracking
CF-14
2
Unit : 0.5 s
0 : Zero tracking OFF
0 Effective
Operation of power on
zero
CF-15
1 Invalidity
0 Operation when it is steady
Operating condition of
tare weight cancellation
CF-16
1 Operation by unconditional
0 Set the district number Method of setting
gravity acceleration
compensation
CF-25
1
Set the numerical value of gravity
acceleration.
0116
District number of using
place
CF-26
(Possible to set at CF250)
10
Unit : District
0116
District number of
calibration place
CF-27
(Possible to set at CF250)
10
Unit : District
Gravity acceleration
value setting of using
place
CF-28
(Possible to set at CF251)
9.000
9.999
9.797
Unit : m/s
2
Gravity acceleration
value setting of
calibration place
CF-29
(Possible to set at CF251)
9.000
9.999
9.797
Unit : m/s
2
0 Range change OFF
1 Changeable two ranges
Range switch operation CF-40
2 Changeable three ranges
has been set as default.
