Minebea CSD-904-EX User Manual

26
4-7. LOCK of calibration
The function change in the calibration and C function can be prohibited by the switch of rear panel.
4-7-1. LOCK by the switch
There is calibration LOCK switch in the inside when the
cap under the load cell connector of rear panel is
removed.
The LOCK effective/invalidity can be set with calibration
LOCK switch.
● When the calibration LOCK is at the effective, the mode of “ ” or “ ” cannot be used.
LOCK switch of
calibration
Load cell connector
LOCK OFF LOCK ON
