101
16. Error display
Display blinking for about 2 seconds when C function or function is set and no number
in the list is selected.
Display blinking for about 2 seconds when the calibration is executed, and “Display of
the maximum capacity(DISP)” < “Set of mass weight value(LOAD)” is set.
A/D conversion error. Please contact with MINEBEA.
EEPROM writing error. Please contact with MINEBEA.
EEPROM reading error. Please contact with MINEBEA.
Display blinking for about 2 seconds when the calibration is executed, and output of
the load cell and numeric input is –2.5 mV/V or less and exceeding the zero
adjustment range at the minus side.
Display blinking for about 2 seconds when the calibration is executed, and output of
the load cell and numeric input is 2.5 mV/V or more and exceeding the zero
adjustment range at the plus side.
Display blinking for about 2 seconds when the calibration is executed, and output of
the load cell and numeric input is less than 0 mV/V and not reaching within the span
adjustment range.
Display blinking for about 2 seconds when the calibration is executed, and output of
the load cell and numeric input is more than 3.1 mV/V and exceeding the span
adjustment range.
Display blinking for about 2 seconds when the digital linearization compensation is
executed and the load cell output is low.
Display blinking for about 2 seconds when the digital linearization compensation is
executed and the load cell output is high.
(When C function CF-15 “Power on zero operation” is effective.)
Displayed when the power is turned on or the display is ON with the condition of the
load cell output exceeding ±10 % of the maximum capacity.
If the key is pressed with “ ” displayed, it compulsorily becomes a
load value display.
Light on when the load display is exceeding “(+Maximum capacity) + 9D”, or exceeding
“+110 % of the maximum capacity”. (by the setting of C function CF-03)
Light on when the load display is exceeding “(-Maximum capacity)-9D”, or exceeding
“-110 % of the maximum capacity”. (by the setting of C function CF-03)
The input to A/D converter is plus over.
The input to A/D converter is minus over.
Condition display of
“Accumulation” is
blinking
Display blinking when the result of accumulated value or the accumulated counts is
exceeding the display range.
All lights on
When the stability cannot be detected with the power turning on, or the display ON.
When the stability detection is turned off either with the function F-10 and F-11, the
display becomes all lighting on.
To Next Page
