15. Specifications
15-1. Specifications for analog
Bridge power supply DC5 V±0.25 V within 120 mA with sensing
Applicable transducer Up to 8 pieces of strain gage applied transducers(350 ohm) can be connectable.
Input sensitivity 0.2 μV/d or more (d＝The scale interval)
Input range －3.1 mV/V to 3.1 mV/V
Zero adjustment range ±2.5 mV/V
Non linearity 0.01 %F.S.
Zero ±0.2μV/℃(At the calibration with input sensitivity 0.2μV/d or more.)
Temperature
coefficient
Sensitivity ±0.001 5 %F.S./℃(At the calibration with input sensitivity 0.2μV/d or more.)
Input noise ±0.4μVp-p or less(At the default setting of digital filter and stabilization filter)
Input filter Approx. 1 Hz (At the default setting of digital filter and stabilization filter)
A/D sampling 15 times/s
15-2. Specifications for digital
Load display
Display range
－999 999 to 999 999
(Display of accumulated total value －1 999 999 to 9 999 999, and accumulated
counting value 0 to 999 999)
Display increment 1 (changeable to 2, 5, 10, 20 or 50)
Display range 7-segment green colored fluorescent display tube with 22 mm character height
Over display “-OL” display at minus over and “OL” display at plus over
SAD value over
display
“-OVF” display at minus over and “OVF” display at plus ove
Status display
Accumulation, Stable, Fixed tare weight cancellation, Tare weight cancellation,
Gross value, Net value, Zero
Judgement display
HI、OK、LO (OK : Green colored fluorescent display tube, HI and LO : Orange
colored fluorescent display tube)
Display frequency 5 times/s (Changeable to 15 times/s）
Decimal point display Changeable to no display, 10
1
, 10
2
or 10
3
Unit display Changeable to nothing, g, kg, t or lb (Green colored fluorescent display)
15-3. Interface
External control input
The external control operation of 7 pieces in the following can be made with
INPUT connector.
ON/OFF, Setting, Accumulation, Set of tare weight cancellation, tare weight
cancellation, Net value/Gross value, Zero, Print, Display of net value, Display of
accumulated value.
Serial interface
Two-wires method interface output for connections such as printer, external
display, and so on.
Contact output (Option)
Relay contact output : 3 points
Specifications of contact : 1a contact,
AC250 V 3 A, DC30 V 3 A (Load resistance)
Comparator function : Upper/Lower limit comparative mode, Weigh-in mode,
Weigh-out mode.
