67
Configuration
If the i
3
maintenance test is selected within six minutes after power-up or reset, the following
information message is displayed.
Figure 42 i
3
test not ready
If a zone is selected that is not configured as an i
3
zone, the following message is displayed:
Figure 43 The selected zone is not i
3
type
When the zone goes into the i
3
loop test, no other zone can be put into the test. The
maintenance test takes five minutes. During this time you can walk through the device and
make sure all the devices are working properly. The following table lists the status of the
devices while in loop test.
You can cancel the maintenance test either by pressing the RESET button or by going into the
configuration section and canceling the test.
11.12 Dialer Config (Command Menu)
Figure 44 shows the dialer configuration menu.
Figure 44 Dialer Config menu
Note: Out of sensitivity can mean the device is dirty.
Table 8 i
3
Detector LEDs while in test mode
i
3
Detector Condition
Green LED Red LED
Proper operation Double blink every 5 sec OFF
Out of sensitivity OFF Double blink every 5 sec
Freeze condition OFF Double blink every10 sec
The selected zone
is not ready yet
The selected zone
is not i3 type
1 Account Info
2 Telephone line
3 Report Options
4 Time Parameter
-Dialer Config-
5 Enable/Disable
6 Ring Detect
To Next Page
