53
Configuration
11.1 Accessing Configuration Mode
To access configuration mode
1. Press the Menu button on the front panel display.
2. Enter your passcode.
The minimum number of digits for the passcode is four and the maximum is ten. The
passcode must be numerical values only. The default passcode is 1111.
3. Press the ENTER button.
The main command menu appears.
If the passcode is wrong, the system prompts you to re-enter the passcode. After three
tries the system takes you back to the normal message display.
Figure 32 Enter passcode
11.2 Command Menu
The command menu is shown in Figure 33. The first line of the LCD always displays
-Command Menu-, and the second line scrolls through different selections.
To scroll through the menu
• Use the up and down arrow buttons, and then press the ENTER button to make a
selection.
To exit from the command menu
• Select the Exit menu option, and then press the ENTER button.
Note: Close jumper JW5 on the main board to access Command Menu features 1 and
9.
