Mircom FA-301-12DDR User Manual

71
Configuration
Command Menu-->Dialer-Config
11.12.4Time Parameters
Figure 48 Time Parameter
Command Menu - Dialer-Config - Report Options
3. Supervisory priority
[X] Account 1->Def
[ ] Account 2
Use this menu to set the
account priority for
reporting supervisory
troubles. If the priority is
set for account #1, then the
dialer will try account #1
first for reporting.
Command Menu - Dialer-Config - Report Options
4. “Aux. Disconnect” Cancels Alarm
& Supv Reporting Thru Dialer
[ ] ENABLE
[X] DISABLE ->Default
If this function is enabled,
the “Aux Disconnect”
command (see page 75)
will block the alarm and
supervisory events from
the being reported through
the dialer.
Command Menu - Dialer-Config - Report Options
5. Fire Panel type
[X] FA-300 Panel->Def
[ ] FA-1000 Panel
[ ] FX-2000 Panel
Do not change this menu;
keep it as default.
For factory use only.
Command Menu - Dialer-Config - Report Options
6. Dialer operation mode
[X] (U)DACT ->Default
[ ] DACT
Use this function to select
the functionality of the
dialer. In DACT mode only
common trouble/alarm/
supervisory are reported
while in UDACT mode all
point information is
reported
Command Menu - Dialer-Config - Report Options
7. Checksum Bits
[X] 8 Bit ->Default
[ ] 16 Bits
Do not change this
function; keep it as default
For factory use only.
Command Menu - Dialer-Config - Time Parameter
1. AC Loss delay
0 ->Default
0 to 20 hours
Use this menu to delay the
reporting of AC loss trouble on the
dialer for the specified time
period.
SUPV Priority
[X] Account 1
AuxDis Alm&Supv Rpt.
[X] DISABLE
Fire Panel Type:
[X] FA-300 Panel
Dialer Oper. Mode:
[X] (U)DACT
Checksum Bits:
[X] 8 Bits
1 AC-Loss Delay
2 Cellphone Date
3 Auto-Test Time
-Time Parameter-
AC-Loss Delay(Hrs)
0
