11.18.1Example 1 (detection circuit)
Event 02 of 09, OPEN TRB on initiating circuit Z-01 in the EAST LOBBY ENTRANCE with
process type as VERIFIED ALARM and the event occurred on 2003/02/02 at 18:01
TUESDAY.
Figure 50 Detection circuit message
11.18.2Example 2 (indicating circuit)
Event 02 of 09, SHORT TRB on indicating circuit NAC-01 in the EAST WING LOBBY with
process type as SILENCEABLE and the event occurred on 2003/02/02 at 18:01 TUESDAY.
Figure 51 Indicating circuit message
Other common messages are described below.
Note: The queue hierarchy is Alarm, Supervisory, Trouble and Monitor. Alarm has the
highest priority and is always shown at the beginning of the queue, followed by
supervisory alarms, troubles and monitor zone troubles.
EAST LOBBY ENTRANCE
OPEN TRB 01/09
VERIFIED ALARM Z-01
18:01 TUE 2003-04-04
ZONE
Message
EVENT
01 of 09
Process
Type
Physical
Zone No.
DATE
TIME
"INFO" Key
EVENT
type
EAST WING LOBBY
SHORT TRB 02/09
SILENCE-ABLE NAC-1
18:01 TUE 2003-02-02
"INFO" Key
ZONE
Message
EVENT
type
EVENT
02 of 09
Process
Type
Physical
Zone No.
DATE
TIME
i
