What to do if Mircom FA-301-12DDR Control Panel shows Battery Trouble?
If your Mircom Control Panel indicates a Battery Trouble due to low voltage (below 20.4 V), replace the batteries as soon as possible.
How to fix Common Trouble on Mircom Control Panel?
To address a Common Trouble issue on your Mircom Control Panel, check for the following potential faults: missing interconnection wiring, any missing module that was part of the configuration, or improperly secured cabling.
What to do if Mircom FA-301-12DDR Control Panel shows Ground Fault?
If your Mircom Control Panel displays a Ground Fault, check for any external wiring that might be touching the chassis or any other earth ground connection.
How to troubleshoot Circuit Trouble in Mircom Control Panel?
To troubleshoot a Circuit Trouble in your Mircom Control Panel, check for open wiring on the affected circuit. Also, verify that the circuit is not disconnected or bypassed.
General| Type | Fire Alarm Control Panel |
|---|---|
| Model | FA-301-12DDR |
| Zones | 12 |
| Voltage | 24 VDC |
| Communication | Optional DACT (Digital Alarm Communicator Transmitter) |
| Dimensions | 14.5" H x 12.5" W x 3.5" D |
| Operating Temperature | 0°C to 49°C (32°F to 120°F) |
| Relative Humidity | 93% non-condensing |
| Input Voltage | 120V AC |
Details connections, DIP switches, and jumpers on the main fire alarm board for setup.
Explains wiring and connections for the ICAC-306 input Class A converter module.
Illustrates wiring diagrams for connecting devices to the main fire alarm board.
Provides guidance on identifying and resolving common system issues and faults.
Guides on how to enter the system's configuration mode using the passcode.
Explains navigation through the main command menu and its options.
