Appendix C: Specifications
Battery Type 24 VDC (2x12 VDC), sealed lead acid, 6 Ah
maximum
Charging capability 10 Ah
Protection 10 A on board (F1) slow blow micro fuse
Compliance System Model FA-300 Series LED Version Fire Alarm Control
Panel
System Type Local, Auxiliary (using PR-300), Remote Protected
Premises Station (using PR-300 or FA-301-12LDR,
FA-301-12LDW, or FA-301-8LDW) Central Station
Protected Premises (using FA-301-12LDR, FA-301-
12LDW, or FA-301-8LDW).
Type of Service A, M, WF, SS
Type of Signalling Non-Coded
Applicable Standards NFPA 70 and 72, UL-864 Rev. 9
Table 13 FA-300 LCD System Modules and Annunciators
FA-300 LCD Series Modules and Annunciators
RM-312/306 Relay Adder Module Must be connected to a listed power-limited
source of supply.
Contact rating NO / NC / 28 VDC per contact / 1 A resistive
load max
Current consumption standby 0 mA, alarm 80 mA
ICAC-306 Input Class A converter module standby: 0 mA / alarm: 0 mA
OCAC-304 Output Class A converter Module standby: 0 mA / alarm: 0 mA
OCAC-302 Output Class A converter module Standby 0 mA / alarm 0 mA
SRM-312 Smart Relay Module Must be connected to a listed power-limited
source of supply
Contact rating FormC/ 28 VDC per contact /
1 A resistive load max, zoned
Current consumption standby 30 mA / alarm
140 mA
Contact rating FormC / 28 VDC per contact / 1 A resistive
load max, zoned
Current consumption standby 30 mA, alarm 140 mA
RAM-300 Remote LCD Annunciator Standby 16 mA / alarm 40 mA
RAM-208 8 Zone Remote Annunciator Standby 35 mA / alarm 90 mA
Table 12 FA-300 LCD Series Specifications (Continued)
FA-300 LCD Fire Control Panel Chassis
