Configuration

RESET button to restore power to the system. If the short is removed, the panel returns to

normal; otherwise the trouble message remains.

Figure 56 Four-wire smoke detector supply message

11.24 Supervised auxiliary supply

The supervised auxiliary supply is supervised for shorts. When a short is detected on the

supervised auxiliary supply, the power is cut off and a trouble message is generated. Press the

RESET button to restore power to the system. If the short is removed, the panel returns to

normal; otherwise the trouble message remains.

Figure 57 Supervised auxiliary supply message

11.25 City tie Polarity reversal - PR-300/Relay module

The city tie or polarity reversal module is supervised for open and whether or not the PR-300

is plugged in. The relay module is supervised for whether or not it is plugged in.

Note: The trouble code and info is for trained service personnel only.

"INFO" Key

4Wire Pwr. Supply

short 1/ 1

Trouble Type

EVENT

01 of 01

Trb:0x03 Info:0x0001

00:07 SAT 2000-01-01

DATE

TIME

Trouble code Trouble Info
