Introduction

Version 5.4 TX3 Telephone Access System Installation and Operation Manual 19

1.4 Lobby Control Unit Accessories

The Lobby Control Unit accessories consist of the following items:

• TX3-UFT Universal series flush trim ring.

• TX3-USFT Slim line Universal Series flush trim ring.

• TX3-UGA Gooseneck mounting adapter designed for use with the

standard Universal Series enclosure for pedestals.

• TX3-USGA Gooseneck mounting adapter designed for use with the TX3-

200-4U Slim Line Universal enclosure pedestals.

• TH-102 Thermostat Heater with one PS-24P Transformer Plug

• CAM-3 TX3 Camera

• TX3-MDM Modem Module

• TX3-GPM Guard Phone Module

• TX3-USB-AD USB to RS-485 Adapter

• TX3-IP IP Module

• TX3-P300-HA Mullion mount card reader. Fits inside panel

• TX3-CX-1NP Single Door Control Module, PoE, 12 VDC, 24-48 VDC
