56 TX3 Telephone Access System Installation and Operation Manual Version 5.4

Lobby Control Unit Setup

4.2.7 Power Supply

The power supply connection is situated at the bottom right of the main controller

board and receives 16 Vac, 40 VA. An external PS-4 or PS-4P plug-in

transformer connects to the power terminals. Refer to figure 29 and figure 33.

Figure 33. Power Supply

16 Vac IN

OFF ON

SW2

120 Vac

16 Vac

16 Vac transformer

(PS-4 or PS-4P)

ON/OFF Switch

Note: Use 18 AWG
