Version 5.4 TX3 Telephone Access System Installation and Operation Manual 39

All units use the PS-4P transformer for the power supply. The door strike power

supply depends on the door strike power requirements.

3.2 Single Lobby Control Unit

Figure 17 shows the simplest configuration.

Figure 17. Single Lobby Control Unit

Line1

NSL

Control

Unit

1 2 3

4 5 6

7 8 9



* 0 # i

T/R

1 2 3

4 5 6

7 8 9



* 0 # i

Line1

Telephone outlet

Central office line
