40 TX3 Telephone Access System Installation and Operation Manual Version 5.4

TX3 System

Figure 18 shows a configuration using one Lobby Control Unit connected to one

ADC line and four NSL lines.

Figure 18. Single Lobby Control Unit with ADC and NSL Lines

Line2

Line3

Line4

Line5

NSL

Control

Unit

NSL

Control

Unit

NSL

Control

Unit

NSL

Control

Unit

1 2 3

4 5 6

7 8 9



* 0 # i

Line1

Telephone outlet

Central office line

T/R

T/R T/R

T/R
