Lobby Control Unit Setup
Version 5.4 TX3 Telephone Access System Installation and Operation Manual 67
LT-969 Copyright 2019
• Ethernet connection (Lobby Control Unit must have an IP Module)
• Modem connection (Lobby Control Unit must have a Modem Module)
The TX3 system is compatible with the following modems:
• TrendNet TFM-560U High Speed USB 2.0 Fax Modem
• TrendNet TFM-561U High Speed USB 2.0 Fax Modem
• Hiro H50113 56K V.92 USB Fax Modem
• StarTech USB56KEM2 56k V.92 USB Fax Modem
• Zoom 56K V.92 56K USB Mini External Fax Modem
• USRobotics USR5639 56K USB Softmodem
Additional modems are currently being tested for compatibility.
The TX3 configuration is set using either the unit’s own keypad and display or
via the PC Configuration Software.
4.10.1 PC System Requirements
See LT-995 Touch Screen Administrators Guide for information on installing
the TX3 Configurator software.
4.11 Updating Firmware
You can update the firmware on your panel with the TX3 Configurator software
by using one of the following methods.
• Firmware Upgrade Wizard
• Network Firmware Upgrade
The Firmware Upgrade Wizard can be used to update only one panel at a time. It
will work on any panel. This method does not work on 64-bit versions of
Windows.
The Network Firmware Upgrade procedure can update more than one panel at
the same time. In order to use the Network Firmware Upgrade, all of the panels
must already have firmware that supports this feature installed on them.
Refer to LT-995, TX3 Configuration and Administrator Manual, for instructions
on how to perform both of these firmware upgrade methods. LT-995 can be
found on the TX3 Configurator Software installation CD, USB flash drive, or on
the Mircom website.
4.11.1 Firmware Version Control
The firmware version number is accessible from the Configurator software and
changes whenever there is a major, minor or revision update.
