Enclosure Installation

Version 5.4 TX3 Telephone Access System Installation and Operation Manual 33

4. Remove the 6 nuts on the reinforcement bracket, as show in figure 9, and

then remove the bracket.

Figure 9. Reinforcement Bracket with nuts

5. Remove the remaining 8 bolts that attach the Kiosk to the base plate, as

shown in figure 10.

Figure 10. Kiosk Base Plate with bolts

Nuts (x6)

Reinforcement Bracket

Bolts (x8)

Base Plate
