48 TX3 Telephone Access System Installation and Operation Manual Version 5.4

4 Lobby Control Unit Setup

This chapter describes the Lobby Control Unit controller board components and

provides information about its operation and setup

This chapter explains

• Controller Board

• Modem Module

•IP Module

• RS-485 Add-on Module

• Guard Phone Module

•Guard Phone

• Controller ID Setup

• Configuration Using a PC

• Updating Firmware

• Beginning Configuration
