Lobby Control Un
it Setup
Version 5.4
TX3 Telephone Access Syste
m Installation and Operati
on Manual
49
LT-969
Copyright 2019
4.1
Controller Board
Figure
27 shows the general layout of
the Lobby Control Un
it main controller
board. See section 4.2 on page 51 and
sectio
n 4.3 on page 57 for a detailed
description of the connectors at the
bottom and top of the controller board.
Figure
27.
Lobby Control Unit Main Controller Board on Models
Ending in
-C
T
elephone
lines 1 to 5
Door Supply
, Door
Relay
, and 2 General
Purpose Relay
s
JW8
P7: Guard Phone
Connection
SW1: DIP
Switches
P5: Ethernet Board
Connection
USB Port
P4: Modem
Connection
JW7
JW1
JW2
JW5
JW10
JW9
JW11
P6: T
o
Keypad/
Display
SW1:
Pow
er
48
50
