74 TX3 Telephone Access System Installation and Operation Manual Version 5.4

NSL Relay Cabinet Installation and Wiring

The expanders allow a total of 16 backplanes to be installed, allowing for up to

1535 relays.

Note: The TX3-NSL-8M and any TX3-8EC and/or TX3-16EC must all

be adjacent to each other, mounted on the same wall and in the same

room.

Figure 42. NSL Expanders

Each slot

accepts a

2012 NSL

Relay

Board

TX3-NSL-8M

NSL Unit

TX3-8EC NSL

Relay Backplane Expander

TX3-16EC NSL

Relay Backplane Expander
