66 TX3 Telephone Access System Installation and Operation Manual Version 5.4
LT-969 Copyright 2019
Lobby Control Unit Setup
4.10 Configuration Using a PC
In order to correctly utilize the capabilities of the TX3 Telephone Access System
you must first plan and establish how you want to configure the system for your
application.
The easiest way to configure the Lobby Control Unit is with the Mircom TX3
Configuration Software. This software is provided on a single CD-ROM or USB
flash drive.
The PC connects to the Lobby Control unit controller board using one of the
following methods:
• USB cable from the PC to the TX3 Main Lobby board
37 ON OFF ON OFF OFF ON
38 OFF ON ON OFF OFF ON
39 ON ON ON OFF OFF ON
40 OFF OFF OFF ON OFF ON
41 ON OFF OFF ON OFF ON
42 OFF ON OFF ON OFF ON
43 ON ON OFF ON OFF ON
44 OFF OFF ON ON OFF ON
45 ON OFF ON ON OFF ON
46 OFF ON ON ON OFF ON
47 ON ON ON ON OFF ON
48 OFF OFF OFF OFF ON ON
49 ON OFF OFF OFF ON ON
50 OFF ON OFF OFF ON ON
51 ON ON OFF OFF ON ON
52 OFF OFF ON OFF ON ON
53 ON OFF ON OFF ON ON
54 OFF ON ON OFF ON ON
55 ON ON ON OFF ON ON
56 OFF OFF OFF ON ON ON
57 ON OFF OFF ON ON ON
58 OFF ON OFF ON ON ON
59 ON ON OFF ON ON ON
60 OFF OFF ON ON ON ON
61 ON OFF ON ON ON ON
62 OFF ON ON ON ON ON
63 ON ON ON ON ON ON
Table 2: Lobby Control Unit SW1 DIP Switch Settings (Continued)
Lobby Control Unit ID # Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6
