NSL Relay Cabinet Installation and Wiring

Version 5.4 TX3 Telephone Access System Installation and Operation Manual 75

5.3 Wiring the TX3-NSL-8M Main Controller Board

The TX3-NSL-8M NSL Main Controller Board has both ribbon cable sockets

and screw terminals.

Attention: High voltages are present on this board during the ringing of suite

telephones.

Figure 43 shows the general layout of the TX3-NSL-8M Main Controller board

components.

Figure 43. TX3-NSL-8M Main Controller Board

5.3.1 Connectors

USB. Computer connection for firmware download.

P1 and P2. Not used.

P3. Not used.

SW1

OFF

USB

16V AC

JW1

JW2

Telephone Line

from Lobby Pane

Main Controller

Board

Res.

Co.

X3-NSL-8M Relay Control Unit

Expansion Connectors

TX3-NSL-8M Main Controller Board

P1 P2

SW2

TS5

TS4
