Enclosure Installation

Version 5.4 TX3 Telephone Access System Installation and Operation Manual 23

2.2.1 Installing the Universal enclosure

Figure 1. Dimensions of Universal Series Models

10” (254 mm)

16 5/8”

(422 mm)

4 1/2” (114 mm)

3 3/8”

(86 mm)

7 21/32” (194 mm)

13 3/4”

(394 mm)
