NSL Relay Cabinet Installation and Wiring

Version 5.4 TX3 Telephone Access System Installation and Operation Manual 73

5.2.2 2012 NSL Relay

The NSL Backplane board contains up to eight 2012 NSL Relay Boards. Each

2012 NSL Relay Board has 12 relays, allowing for a total of 96 relays.

5.2.3 NSL Expanders

NSL expanders plug into the NSL Backplane Board connectors and consist of:

• TX3-8EC NSL Eight Relay Card Backplane Expander

• TX3-16EC NSL 16 Relay Card Backplane Expander

Extension cables provide connections between adjacent enclosures using the

expansion connectors. See section 5.3 on page 75 for a description of the NSL

Backplane Board connectors.

The TX3-8EC NSL Eight Relay Backplane Expander and the TX3-16EC

NSL 16 Relay Backplane Expander are housed in their own cabinet and can be

connected with two cables to provide an additional capacity for 8 or 16 relay

boards respectively.
