NSL Relay Cabinet Installation and Wiring

Version 5.4 TX3 Telephone Access System Installation and Operation Manual 71

The top two mounting holes are 6 3/16 inches apart.

To mount the NSL Relay Cabinet

1. Using the back cover as a template mark the top two mounting hole

locations 6 3/16 inches apart as shown in figure 40.

2. Place the screws halfway into the wall in the position shown using a

suitable screw.

3. Hang the box onto the two screws.

4. Screw the other two screws at the bottom of the panel.

5. Tighten all four screws into place.

Table 3: NSL Relay Cabinet Dimensions

Model Number Dim ‘A’ Dim ‘B’

TX3-8EC 10 1/8” 13 15/16”

TX3-NSL-8M 23 3/16” 27”

TX3-16EC 23 3/16” 27”
