NSL Relay Cabinet Installation and Wiring

Version 5.4 TX3 Telephone Access System Installation and Operation Manual 85

Figure 49. 2012 NSL Relay Board

This connector mounts

into the NSL backplane

Amphenol connection

from telephone company

LEDs
