Adding Controllers and Accessories

Version 5.4 TX3 Telephone Access System Installation and Operation Manual 95

3. Attach the card reader with the same screws.

Figure 53. Install TX3-P300-HA

4. See LT-980 TX3-CX Card Access System Installation for instructions on

connecting the card reader to the TX3-CX Card Access system.

TX3-P300-HA card reader

Screws (x2)
