Mircom TX3 Series - Adding Controllers to TX3 System

104 TX3 Touch Screen Installation Manual
Touch Screen System and Setup
Figure 92. New card reader bracket
3. Remove the current card reader from the bracket and attach the
replacement card reader to the bracket with the nuts or screws as shown in
Figure 93 and Figure 94.
Figure 93. Card reader and old bracket
Posts(x4)
Card Reader
and Bracket
Nuts (x4)
Bracket
Card Reader
Screws (x2)
