Touch Screen Factory Wiring
TX3 Touch Screen Installation Manual 129
Figure 132. Factory connections on the lobby controller board for
TX3-TOUCH-S22 and TX3-TOUCH-F22 for MD-1236
Figure 133. Factory connections on the PC sub compact board for
TX3-TOUCH-S22 and TX3-TOUCH-F22 for MD-1236
WX-110: TS1 on
MD-1236
TS4
WX-109: TS12 on
MD-1236
(not polarity sensitive)
TS2
WX-077:
Microphone
JP1
WX-053: USB on
PC board
WX-030: Postal
lock switch
(optional)
TS5
TS2
Power switch
+
−
WX-070:
Ground wire
to MD-1236
Black
White
Red
Black
Red
BlackRed
CN6
CN2
CN1
CN31
CN15
CN32
Camera
USB
Touch Screen VGA
cable
CN14
CN4
WX-080: P2 on
MD-1236
WX-081: P3 on
MD-1236
WX-082:
USB to display
WX-089:
USB extension
WX-079: P1 on
MD-1236
WX-053: JP1 on
telephone access
controller
Battery
BAT1A
WR-21160 and
WR-21162: TS10A on
MD-1236
+
−
Red
Black
Optional Fan
CN3
