3 Touch Screen System and Setup
This chapter describes the basic Touch Screen system, main panel, controller
board components and provides information about its operation and setup.
This chapter explains
• Installation Prerequisites
• Touch Screen System
• TX3-TOUCH-K15-A, TX3-TOUCH-F15-A, TX3-TOUCH-S15-A
Main Panel, Boards, and Grounding
• TX3-TOUCH-F15-B/C/D and TX3-TOUCH-S15-B/C/D Inside Door,
Boards, and Grounding
• TX3-TOUCH-F22(-C/D) and TX3-TOUCH-S22(-C/D) Inside Door,
Boards, and Grounding
• TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR Inside Door,
Boards, and Grounding
• Lobby Controller Board
• Connecting to the External Power Supply
• Turning the Touch Screen On and Off
• Installing the Postal Lock on TX3 Touch Indoor Units
• Installing the Telephone Lines
•Ethernet
• Beginning Configuration
• Installing Other Optional and Replacement Components
• RS-485
• Installing the P1264 IP camera
• Replacing the Display on the 22” Touch Screen
• Installing the Optional TX3-DELTA5 Card Reader
