Introduction
TX3 Touch Screen Installation Manual 15
Features of TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR include:
•
Vandal resistant enclosure to endure high external impact
•
1600 nits high brightness display
• 15” color anti-glare, industrial grade, 6.4mm thick glass touch screen
display
•
Touch screen works under any weather condition – rain, snow and even
when the user is wearing gloves
•
Two locks for added security
•
Bottom firing speaker is perfect for outdoor application
• Built-in TCP/IP capability for remote programming
• Built-in HD camera and built-in proximity card reader for easy integration
to access control panels
• Provision to add optional HD IP camera
1.3 Touch Screen Sizes and Enclosures
1.3.1 15 Inch Indoor Models
The 15 inch Touch Screen models are stand alone, surface or flush mounted.
TX3-TOUCH-K15. 15” Touch Screen kiosk, stainless steel finish Touch
Screen with speaker, microswitch for postal lock, and external power supply.
Designed for indoor use.
TX3-TOUCH-K15-A. 15” Touch Screen kiosk, stainless steel finish Touch
Screen with speaker, microswitch for postal lock, and external power supply.
Designed for indoor use. Can be configured as a Master Node on an Ethernet
network.
TX3-TOUCH-F15. 15” Touch Screen flush mount, stainless steel finish Touch
Screen with speaker, microswitch for postal lock, external power supply, and
flush mounting back box. Designed for indoor use.
TX3-TOUCH-F15-A, TX3-TOUCH-F15-B, TX3-TOUCH-F15-C,
TX3-TOUCH-F15-D. 15” Touch Screen flush mount, stainless steel finish
Touch Screen with speaker, microswitch for postal lock, external power supply,
and flush mounting back box. Designed for indoor use. Can be configured as a
Master Node on an Ethernet network.
TX3-TOUCH-S15. 15” Touch Screen surface mount, stainless steel finish
Touch Screen with speaker, microswitch for postal lock, external power supply,
and surface mounting back box. Designed for indoor use.
