Installation
TX3 Touch Screen Installation Manual 37
Figure 17. TX3-TOUCH-S22(-C/D) dimensions (inches)
34.118
18.000
70.00°
(X2)
17.000
31.000
12.600
20.350
2.500
5.325
10.825
5.225
4.125
