36 TX3 Touch Screen Installation Manual
Installation
Figure 16. TX3-TOUCH-F22(-C/D) dimensions (inches)
32.000
18.000
4.000
4.177
31.000
12.600
12.750
8.000
12.450
10.825
5.225
17.000
