24 TX3 Touch Screen Installation Manual
Installation
2.2 Installing TX3-TOUCH-F15-A
Figure 7. TX3-TOUCH-F15-A flush mount back dimensions
(inches)
12.600 12.600
18.000 18.000
12.750 12.750
20.750 20.750
2.825 2.825
13.800 13.800
0.213 0.213
23.825 23.825
3.500 3.500
2.500 2.500
21.225 21.225
0.218 0.218
1.400 1.400
1.200 1.200
