112 TX3 Touch Screen Installation Manual
Touch Screen Factory Wiring
4.1.2 Factory Wiring for TX3-TOUCH-S22-D and TX3-TOUCH-F22-D
Figure 104. Factory connections on the power supply and audio
mixer board for TX3-TOUCH-S22-D and
TX3-TOUCH-F22-D
Figure 105. Factory connections on the power button
WX-095: JP19 on MD-1346
WX-079: CN9 on MD-1346
WX-109: TS2 on MD-1245
(not polarity sensitive)
WR-22160 and WR-22162:
CN7 on MD-1346
+
WX-110:
TS4 (top) on MD-1245
WR-12223 and WR-12224:
Left Speaker
WR-12223 and WR-12224:
Right Speaker
WX-080:
CN5 on MD-1346
P3
P1
TS1
TS4A
TS12
P2
TS9
SW-207: Button
WR-21160 and
WR-21162: Power
terminals
TS11
SW3 on the LEFT
TS10A
TS4B
+
−
WX-026:
Ground wire to
chassis ground
WX-070: Ground
wire to MD-1245
+
+
+
Red Black
Red Black
Red
Black
Yellow
Orange
Yellow
Orange
Red
Black
Red
Black
White
Green
MD-1236
−
−
−
−
SW1: all switches o
WC-25019:
Power on display
+
TS10B
Red
Black
−
4
TS11 on
MD-1236
321
Button (bottom view)
Notch
Notch
Button (side view)
black (−)
white
red (+)
green
black (−)
2
green
4
red (+)
1
white
3
