4 TX3 Touch Screen Installation Manual
Contents
3.15 RS-485 94
3.16 Installing the P1264 IP camera 96
3.17 Replacing the Display on the 22” Touch Screen 99
3.18 Installing the Optional TX3-DELTA5 Card Reader 102
4 Touch Screen Factory Wiring 107
4.1 Factory Wiring for Models Ending in -D 108
4.2 Factory Wiring for Models Ending in -C 117
4.3 Factory Wiring for Models Not Ending in -C or -D 123
4.4 Factory Wiring for TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR 139
5 Adding Controllers 143
5.1 Adding a Controller 144
6 Specifications 145
6.1 Indoor Touch Screens 145
6.2 Weather-Resistant Touch Screens 146
6.3 RS-485 TX3-USB-AD Kit 147
6.4 TX3-GPM Guard Phone Module 147
6.5 TX3-CX-1NP 148
6.6 TX3-WIEGAND-OUT 148
7 Resident Operating Instructions 149
7.1 NSL Resident Operating Instructions 150
7.2 ADC Resident Operating Instructions 152
8 Warranty and Warning Information 153
Special Notices 158
