Handset Operations Manual
“Sound off”/”Silent” icon is displayed in the status bar when silent mode is enabled on the
handset.
“Keylock” icon indicates that the keypad is locked, and the user needs to long-press the *-
key to be able to use the handset again.
“Do not disturb” icon is displayed in the status bar when this feature is enabled; in this
case the handset does not react on any incoming calls.
“HD” icon is displayed during a call if the quality of the call is “High Definition” and hereby
using the 722 codec (also called a wideband call).
MENU ICONS
All the menus available on the handset are displayed when the menu key is pressed from
idle. The available menus are seen in the screen below.
The status bar at the top of the display is always displayed independent of which menu is
selected, and the softkey bar shows the possible options to select in every menu. In the
active area of the screen the name of the selected menu is displayed at top, and the available
menus to select are displayed. During navigation across the different menus the highlighted
icon is moves to indicate that it is selected.
Contacts: contains all names/numbers in the local phonebook.
Central directory: contains all names/numbers in the central directory of the system.
This is set up in the web interface of the base station system.
Calls: contains call lists and call times.
Connectivity: contains options to register or deregister the handset and network
options.
Settings: contains personal handset settings such as time and date, language,
handset name, and so forth.
8
