Installation
129
Mitel 470 as of R4.1
syd-0585/1.2 – R4.1 – 08.2016
Tab. 58 Connection of four-fold assigned DSI terminal interface
Communication server
Splitting with fan-out panel
FOP or 8-fold assigned con-
necting cables
Connection socket
Socket Pin DSI signal DSI signal Pin Socket
–1
–2
–3
1a 4
1b 5
–6
–7
–8
–1
–2
–3
2a 4
13a 2b5
23b – 6
32a – 7
41a – 8
51b – 1
62b – 2
74a – 3
84b 3a4
3b 5
–6
–7
–8
–1
–2
–3
4a 4
4b 5
–6
–7
–8








































