Mitsubishi FX1N Series Programming Manual

Introduction 1
1-3
1.4 Special considerations for programming equipment
1.4.1 Current GenerationCPU all versions
Peripherals Table
Description Model Number
System software version with
full support
Hand held programmer (HHP) FX-10P-E from V 3.00
HHP cassette FX-20P-MFXA-E from V 3.00
Data access units/
GOT units
FX-10DU-E from V 4.00
FX-20DU-E Supports up to FX devices only
FX-25DU-E from V 2.00
FX-30DU-E from V 3.00
FX-40DU-E(S) Supports up to FX devices only
FX-40DU-TK-ES from V 3.00
FX-50DU-TK(S)-E from V 2.10
F930GOT-BWD All versions
F94*GOT-SWD(LWD)-E All versions
F94*GOT Handy All versions
F940WGOT All versions
FX1S
FX 1N FX 2N
FX 2NC
The introduction of the current CPU provides the FX user with many new devices and
instructions. To use the full features of the current range of FX units the user must upgrade
older software and hardware programming tools.
However, because of the downward compatibility of the current range, it is not necessary to
upgrade existing programming tools up to the equivalent functionality of last generation FX
CPU ver 3.30 units.

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
