Mitsubishi FX1N Series Programming Manual

FX Series Programmable Controlers Applied Instructions 5
5-141
5.10.7 EMUL (FNC 122)
Operation:
The floating point value of S
1is multiplied with the
floating point value of S
2. The result of the
multiplication is stored at D as a floating point
value.
Points to note:
Point a, b, c and d of the EADD instruction apply, except that a multiplication is performed.
See page 5-122.
Mnemonic Function
Operands
Program steps
S
1 S2 D
EMUL
FNC 122
(Floating
Point Mul-
tiplication)
Multiplies two
floating point
numbers together
K, H - integer value automati-
cally
converted to floating point
D - must be in floating point
format (32 bits).
D-afloating
point value
(32 bits).
DEMUL,
DEMULP:
13 steps
FX 1S
FX 1N FX 2N
FX 2NC
PULSE-P 16 BIT OPERATION 32 BIT OPERATION
DEMUL
M12
D108
K1000 D130

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
