Mitsubishi FX1N Series Programming Manual

FX Series Programmable Controller Diagnostic Devices 6
6-20
6.14 Miscellaneous devices (D8158 to D8164) and
Index Registers (D8182 to D8199)
For symbol key see page 6-1.
*1 See Chapter 10.19.2 for more information
Diagnostic
Device
Operation
Diagnostic
Device
Operation
D8158 (-)
(Not FX2N,FX2NC)
Control device for
FX
1N-5DM*1
Default: k-1
D8187 (
7)
Value of V3 index register
D8159 (-)
(Not FX2N,FX2NC)
Control device for
FX
1N-5DM*1
Default: k-1
D8188 (7)
Value of Z4 index register
D8164 (-)
(Not FX1S,FX1N)
Number of FROM/TO
exchange points
(FX2N/2NC CPU Version 2.00 and
above)
D8189 (7)
Value of V4 index register
D8181 (
7)
Reserved
D8190 (7)
Value of Z5 index register
D8182 (
7)
Value of Z1 index register
D8191 (7)
Value of V5 index register
D8183 (
7)
Value of V1 index register
D8192 (7)
Value of Z6 index register
D8184 (
7)
Value of Z2 index register
D8193 (7)
Value of V6 index register
D8185 (
7)
Value of V2 index register
D8194 (7)
Value of Z7 index register
D8186 (
7)
Value of Z3 index register
D8195 (7)
Value of V7 index register
FX 1S
FX 1N FX 2NC FX 2N

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
