Mitsubishi FX1N Series Programming Manual

FX Series Programmable Controller Diagnostic Devices 6
6-18
For symbol key see page 6-1
M8140 (7)(-)
(Not FX2N,FX2NC)
When ON, clears pulse
output in FNC156(ZRN)
instruction
D8140
D8141
(
7)(-)
Contains the total number of
pulses that have been output
to Y0 using the PLSY or PLSR
instructions. This data is only
available in 32 bit or double
word format.
M8141 to
M8144
Reserved
D8142
D8143
(
7)(-)
Contains the total number of
pulses that have been output
to Y1 using the PLSY or PLSR
instructions. This data is only
available in 32 bit or double
word format.
M8145 (-)
(Not FX2N,FX2NC)
Y000 Pulse output stop
command
D8145 (-)
(Not FX2N,FX2NC)
FNC156(ZRN),
FNC158(DRVI),
FNC159(DRVA) Bias value
setting (default:0)
M8146 (-)
(Not FX2N,FX2NC)
Y001 Pulse output stop
command
D8146 (-)
(Not FX2N,FX2NC)
FNC156(ZRN),
FNC158(DRVI),
FNC159(DRVA)
Max. speed setting
(default:100,000)
M8147 (
7)
(Not FX2N,FX2NC)
Y000 Pulse output monitor
(Busy/Ready)
D8147 (-)
(Not FX2N,FX2NC)
M8148 (7)
(Not FX2N,FX2NC)
Y001 Pulse output monitor
(Busy/Ready)
D8148 (-)
(Not FX2N,FX2NC)
FNC156(ZRN),
FNC158(DRVI),
FNC159(DRVA) Acceleration/
Deceleration time setting
(default:100)
Diagnostic
Device
Operation
Diagnostic
Device
Operation

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
