Mitsubishi FX1N Series Programming Manual

Execution Times And Instructional Hierarchy 7
7-1
7. Execution Times And Instructional
Hierarchy
7.1 Basic Instructions
carried on over the page......
Mnemonic
Object
Devices
Steps
Execution Time in µsec
FX1S FX1N FX2N FX2NC
ON OFF ON OFF ON OFF ON OFF
LD
X,Y,M,S,T,C
and special M
1
0.7
0.08 0.08
LDI
AND
0.65
ANI
OR
ORI
LDP
X,Y,M,S,T,C 1 11.7
-
11.7
-
43.2 43.2
LDF - -
ANDP - -
37.4 37.4
ANDF - -
ORP - -
ORF - -
ANB
Not applicable 1
0.55
0.08 0.08
ORB
MPS 0.5
MRD 0.55
MPP
0.5
INV
MC
Nest level,
M,Y
3 8.6 8.0 8.6 8.0 24.8 27.5 24.8 27.5
MCR Nest level 2 4.1 - 4.1 - 20.8 20.8
NOP
Not applicable 1
0.45 0.08 0.08
END 450 - 450 - 508 508
STL
S
(see note 1)
1
15.8+
8.2n
-
15.8+
8.2n
- 27.3 + 12.6n 27.3 + 12.6n
RET Not applicable 4.8 - 4.8 - 21.6 21.6
FX 1S
FX 1N FX 2N
FX 2NC
FX Series Programmable Controllers

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
