Mitsubishi FX1N Series Programming Manual

FX Series Programmable Controllers Execution Times And Instructional Hierarchy 7
7-8
See end of section for Q notes...
Mnemonic
16/32
Bit
Execution Time in µsec
FX1S FX1N FX2N FX2NC
ON OFF P ON OFF P ON OFF P ON OFF P
88
PID
16 65.5 8.5 65.5 8.5 155.0 89.0 155.0 89.0
89
USER
16 ? ?
4
??
4
??
4
??
4
32?? ?? ?? ??
110
ECMP
32
Not Available
104.4 6.4 4 104.4 6.4 4
111
EZCP
32 124.5 6.4 4 124.5 6.4 4
118
EBCD
32
Not Available
106.9 6.4 4 106.9 6.4 4
119
EBIN
32 81.3 6.4 4 81.3 6.4 4
120
EADD
32 117.4 6.4 4 117.4 6.4 4
121
ESUB
32 117.4 6.4 4 117.4 6.4 4
122
EMUL
32 96.4 6.4 4 96.4 6.4 4
123
EDIV
32 100.4 6.4 4 100.4 6.4 4
127
ESQR
32
Not Available
152.1 6.4 4 152.1 6.4 4
129
INT
16 67.5 6.4
4
67.5 6.4
4
32 70.4 6.4 70.4 6.4
130
SIN
32 199.5 6.4 4 199.5 6.4 4
131
COS
32 262.5 6.4 4 262.5 6.4 4
132
TAN
32 425.3 6.4 4 425.3 6.4 4

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
