Mitsubishi FX1N Series Programming Manual

FX Series Programmable Controllers PLC Device Tables 8
8-3
Item Specification Remarks
State relays
(S coils)
Latched 1000 points S0 to S999
Initial 10 points (subset) S0 to S9
Timers (T)
100 msec
Range: 0 to 3,276.7 sec
200 points
T0 to T199
10 msec
Range: 0 to 327.67 sec
46 points
T200 to T245
1msec
Range: 0 to 32.767 sec
4point
T246 to T249
100 msec
retentive
Range: 0 to 3,276.7 sec
6 points
T250 to T255
Counters (C)
General
Range: 1 to 32,767 counts
16 points
C0 to C15
Type: 16 bit up counter
Latched 184 points (subset)
C16toC199
Type: 16 bit up counter
General
Range: 1 to 32,767 counts
20 points
C200 to C219
Type: 32 bit bi-directional counter
Latched 15 points (subset)
C220 to C234
Type: 32 bit bi-directional counter
High speed
counters (C)
1phase
Range: -2,147,483,648 to
+2,147,483,647 counts
Select upto four 1 phase counters with
a combined counting frequency of
5kHz or less.
Alternatively select one 2 phase or A/B
phase counter with a counting fre-
quency of 2kHz or less.
Note all counters are latched
C235 to C240
6points
1phase
c/w start
stop input
C241, C242 and C244
3points
2phase
C246, C247 and C249
3points
A/B phase
C251, C252 and C254
3points
Data
registers (D)
General 7128 points
D0 to D127 & D1000 to D7999
Type: 16 bit data storage register pair
for 32 bit device
Latched 872 points (subset)
D128 to D999
Type: 16 bit data storage register pair
for 32 bit device
File 7000 points
D1000 to D6999 set by parameter in 3
blocks of 500 program steps
Type: 16 bit data storage register
Externally
adjusted
Range: 0 to 255
2 points
Data is move from external setting
potentiometers to registers
D8030 and D8031)
Special
256 points (inclusive of D8013, D8030
and D8031)
From the range D8000 to D8255
Type: 16 bit data storage register
Index 16 points
VandZ
Type: 16 bit data storage register
Pointers (P)
For use
with CALL
128 points P0 to P127
For use with
interrupts
6 points
I00o to I30o
(rising trigger o =1,
falling trigger o =0)
Nest levels 8 points for use with MC and MCR N0 to N7
Constants
Decimal K
16 bit: -32,768 to +32,767
32 bit: -2,147,483,648 to +2,147,483,647
Hexadeci-
mal H
16 bit: 0000 to FFFF
32 bit: 00000000 to FFFFFFFF

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
